DC12V RGB LED Ribbon
- Item No：FPC12-1000-60LED5050BPC-3P-12V
- views：340
Parameter Feature Detail Application
Item Name: IP67 Waterproof DC12V 29W Breakpoint Continuingly RGB5050 Flexible LED Ribbon Light
Item No.: FPC12-1000-60LED5050BPC-3P-12V
Brand Name: AUXOLED
● Specific Parameters:
Product Dimensions: W12*L1000*T4 (mm)
Light Source: 60PCS SMD5050 LEDs / Meter
Chip Brand: Epistar or Epiled
Beam Angle: 120°
IC Type: Built-in
Input Voltage: DC12V
Power Consumption: 12W
Emitting Color: RGB
PCB Color: White / Black
PCB Material: FPC
IP Class: IP20 / IP65 / IP67
Working Temperature: -20℃~45℃
Working Lifespan: 50,000 Hrs
Can be Used for Both Decoration and Illumination Indoor (IP Class: IP20) and Outdoor (IP Class: IP65 / IP67)
FPC RA Copper Base, Flexible and Good Ductility, Not Easy to Damage
Using High Quality Silicone Glue for IP65 Waterproof and Silicone Tube for IP67 Waterproof, Crystal Clear, Less Sticky Fingerprint and Dust, Good Ductility and Sealing, Will not Turn Yellow in 3 years, Not Easy to Break, Smooth and Elegant Sealing Surface
Intelligent Reverse Connection Protection: In case that Connected to a DC5V Driver by Reversal, will not Damage the LED
Built-in Signal Shaping Circuit: Any Received Signal of Mono Pixel Dot is shaped before Output, to Ensure that the Waveform Distortion will not Superpose
Each Tricolor of Mono Pixel can Achieve 256-stage Brightness Display, can also Display 16,777,216 True Colors, Port Scanning Frequency can Reach 2KHz/s
No Extra Signal Amplifying Circuit is Required within 5m Transmission Distance between each Two Pixel Dots; When the Refresh-rate Reach 30fps, the Concatenated Number is not less than 1024 Dots, and the Speed of Data Transmission can Reach 800Kbps
With Imported Adhesive 3M Tape (Model No.: 300LSE) on the Back of the LED Strip, Better Strength and Viscosity
Using Eco-friendly Reel and Anti-static Ziplock Bag for Packing, 5 Meters per Reel; Can Pack as per Customers' Requirements as Well
DC12V Low Input Voltage, Safe and No Hidden Dangers
Nice Color Consistency, No Flicker, No Radiation, Environmental Friendly and Energy Saving
● Applications:
Supermarket, Shopping Centre, KTV, Architecture, Theatre, Cinema, Exhibition Hall, Cabinet, Kitchen, Counter, Corridor, Cafe, Hotel, Park, Advertising Backlight, Accent Lighting, Sign Illumination, Cove Lighting, etc.
● Certificates:
CE, RoHS
● Warranty:
Item No.: FPC12-1000-60LED5050BPC-3P-12V
Brand Name: AUXOLED
● Specific Parameters:
Product Dimensions: W12*L1000*T4 (mm)
Light Source: 60PCS SMD5050 LEDs / Meter
Chip Brand: Epistar or Epiled
Beam Angle: 120°
IC Type: Built-in
Input Voltage: DC12V
Power Consumption: 12W
Emitting Color: RGB
PCB Color: White / Black
PCB Material: FPC
IP Class: IP20 / IP65 / IP67
Working Temperature: -20℃~45℃
Working Lifespan: 50,000 Hrs
● Detail Form:
| Input Voltage | Emitting Color | Beam Angle | IC Type | IP Class |
| DC12V | RGB |
120° |
Built-in | IP20 / IP65 / IP67 |
| Item No. | Product Dimensions | Rated Power | Light Source | PCB Width |
| FPC12-1000-30LED5050BPC-3P-12V | W12*L1000*T4 (mm) | 6W | 30PCS SMD5050 | 10mm |
|
FPC12-1000-60LED5050BPC-3P-12V |
W12*L1000*T4 (mm) |
12W | 60PCS SMD5050 | 10mm |
|
FPC12-1000-144LED5050BPC-3P-12V |
W12*L1000*T4 (mm) |
29W | 144PCS SMD5050 | 10mm |
● Advantages:
Use Imported Epistar / Epiled Chip LEDs with Built-in IC, Breakpoint Continuously Function, Mono Pixel Dot Dies will not Affect the other Dots and Overall EffectCan be Used for Both Decoration and Illumination Indoor (IP Class: IP20) and Outdoor (IP Class: IP65 / IP67)
FPC RA Copper Base, Flexible and Good Ductility, Not Easy to Damage
Using High Quality Silicone Glue for IP65 Waterproof and Silicone Tube for IP67 Waterproof, Crystal Clear, Less Sticky Fingerprint and Dust, Good Ductility and Sealing, Will not Turn Yellow in 3 years, Not Easy to Break, Smooth and Elegant Sealing Surface
Intelligent Reverse Connection Protection: In case that Connected to a DC5V Driver by Reversal, will not Damage the LED
Built-in Signal Shaping Circuit: Any Received Signal of Mono Pixel Dot is shaped before Output, to Ensure that the Waveform Distortion will not Superpose
Each Tricolor of Mono Pixel can Achieve 256-stage Brightness Display, can also Display 16,777,216 True Colors, Port Scanning Frequency can Reach 2KHz/s
No Extra Signal Amplifying Circuit is Required within 5m Transmission Distance between each Two Pixel Dots; When the Refresh-rate Reach 30fps, the Concatenated Number is not less than 1024 Dots, and the Speed of Data Transmission can Reach 800Kbps
With Imported Adhesive 3M Tape (Model No.: 300LSE) on the Back of the LED Strip, Better Strength and Viscosity
Using Eco-friendly Reel and Anti-static Ziplock Bag for Packing, 5 Meters per Reel; Can Pack as per Customers' Requirements as Well
DC12V Low Input Voltage, Safe and No Hidden Dangers
Nice Color Consistency, No Flicker, No Radiation, Environmental Friendly and Energy Saving
● Applications:
Supermarket, Shopping Centre, KTV, Architecture, Theatre, Cinema, Exhibition Hall, Cabinet, Kitchen, Counter, Corridor, Cafe, Hotel, Park, Advertising Backlight, Accent Lighting, Sign Illumination, Cove Lighting, etc.
● Certificates:
CE, RoHS
● Warranty:
2 Years
