LED Shoes Light Bar
- Item No:FPC2.5-300-48LED3014-1P-12V
- views:284
Parameter Feature Detail Application
Item Name: 2.5mm DC12V 5.76W Flexible LED Backlight Strip with Metal Back
Item No.: FPC2.5-300-48LED3014-1P-12V
Brand Name: AUXOLED
● Specific Parameters:
Product Dimensions: W2.5*L300*T1.5 (mm)
Light Source: 48PCS SMD3014 LEDs
Chip Brand: Epistar
Beam Angle: 120°
CRI: >70
Input Voltage: DC12V
Power Consumption: 5.76W
Color Temperature: 2800-3200K (Warm White), 4000-4500K (Netural White), 6000-6500K (Pure White), 7000-9000K (Cold White)
Luminous Flux: 10-12LM / LED
PCB Material: FPC (with Metal Back)
Working Temperature: -20℃~45℃
Working Lifespan: 50,000 Hrs
2.5mm Super Narrow PCB Design, Good Application Adaptability
FPC RA Copper Base, Flexible and Good Ductility, Comes along with Metal Back for Heat Sink, Not Easy to Damage
Cold White Color Temperature, Uniform Light Ray with High Light Efficiency
DC12V Low Input Voltage, Safe and No Hidden Dangers
No Flicker, No Radiation, Environmental Friendly and Energy Saving
● Applications:
Supermarket, Shopping Centre, KTV, Architecture, Theatre, Cinema, Exhibition Hall, Cabinet, Kitchen, Counter, Corridor, Cafe, Hotel, Park, Advertising Backlight, Accent Lighting, Sign Illumination, Cove Lighting, etc.
● Certificates:
CE, RoHS
● Warranty:
Item No.: FPC2.5-300-48LED3014-1P-12V
Brand Name: AUXOLED
● Specific Parameters:
Product Dimensions: W2.5*L300*T1.5 (mm)
Light Source: 48PCS SMD3014 LEDs
Chip Brand: Epistar
Beam Angle: 120°
CRI: >70
Input Voltage: DC12V
Power Consumption: 5.76W
Color Temperature: 2800-3200K (Warm White), 4000-4500K (Netural White), 6000-6500K (Pure White), 7000-9000K (Cold White)
Luminous Flux: 10-12LM / LED
PCB Material: FPC (with Metal Back)
Working Temperature: -20℃~45℃
Working Lifespan: 50,000 Hrs
● Detail Form:
Input Voltage | Emitting Color | Beam Angle | CRI | IP Class |
DC12V | WW/NW/PW/CW |
120° |
>70 |
IP20 |
Item No. | Product Dimensions | Rated Power | Light Source | Luminous Flux |
FPC2.5-300-24LED3014-1P-12V | W2.5*L1000*T1.5 (mm) | 2.88W | 24PCS SMD3014 | 10-12LM / LED |
FPC2.5-300-48LED3014-1P-12V |
W2.5*L1000*T1.5 (mm) |
5.76W | 48PCS SMD3014 | 10-12LM / LED |
FPC2.5-500-60LED3014-1P-12V |
W2.5*L1000*T1.5 (mm) |
7.2W | 60PCS SMD3014 | 10-12LM / LED |
● Advantages:
Use Imported Epistar Chip LEDs, Super Long Working Lifespan2.5mm Super Narrow PCB Design, Good Application Adaptability
FPC RA Copper Base, Flexible and Good Ductility, Comes along with Metal Back for Heat Sink, Not Easy to Damage
Cold White Color Temperature, Uniform Light Ray with High Light Efficiency
DC12V Low Input Voltage, Safe and No Hidden Dangers
No Flicker, No Radiation, Environmental Friendly and Energy Saving
● Applications:
Supermarket, Shopping Centre, KTV, Architecture, Theatre, Cinema, Exhibition Hall, Cabinet, Kitchen, Counter, Corridor, Cafe, Hotel, Park, Advertising Backlight, Accent Lighting, Sign Illumination, Cove Lighting, etc.
● Certificates:
CE, RoHS
● Warranty:
2 Years
