IP67 LED Module Light
- Item No：AL-LM1.5D-1LED3030-1P-12V
- views：320
Parameter Feature Detail Application
Item Name: DC12V 1.5W High Power IP67 Waterproof SMD3535 LED Module Strip Light
Item No.: AL-LM1.5D-1LED3030-1P-12V
Brand Name: AUXOLED
● Specific Parameters:
Overall Dimensions: L48*W31*T15 (mm)
Center Distance: 153 (mm)
Light Source: 1PC SMD3030 LED
Chip Brand: Cree
Beam Angle: 15*45°
CRI: ＞80
Input Voltage: DC12V
Power Consumption: 1.5W (per Piece)
Driver Type: External Waterproof LED Driver
PF: ＞0.90
Color Temperature: 6500-7000K(Pure White), 7000-7500K(Cold White), 7500-8000K(Cold White)
Luminous Flux: 160-180LM (per Piece)
Main Material: ABS + PMMA
IP Class: IP67
Working Temperature: -40℃~85℃
Working Lifespan: 50,000 Hrs
Each Module has Φ5mm Screw Hole and Imported 3M Tape attached, Easy Installation and Maintenance
DC12V Low Voltage Input, Safe and No Hidden Dangers
PMMA Lens, Excellent Light Transmittance Effect, Uniform Light Color and No Glare
The Module Quantity of Each String can Reach 20PCS, IP67 Waterproof, Best Choice for the Backlight of Huge Outdoor Advertising Light Box
PSE Approved, Gorgeous Product for Japan Market
No Flicker, No Radiation, Environmental Friendly and Energy Saving
● Applications:
Advertising Light Box, Advertising Signboard, Cabinet, Corridor, Supermarket, Cloth Store, Museum, Hospital, KTV, Architecture, Theatre, Cinema, Hotel, Cafe, Park, Commercial Centre, Villa, etc.
● Certificates:
CE, RoHS, PSE
● Warranty:
Item No.: AL-LM1.5D-1LED3030-1P-12V
Brand Name: AUXOLED
● Specific Parameters:
Overall Dimensions: L48*W31*T15 (mm)
Center Distance: 153 (mm)
Light Source: 1PC SMD3030 LED
Chip Brand: Cree
Beam Angle: 15*45°
CRI: ＞80
Input Voltage: DC12V
Power Consumption: 1.5W (per Piece)
Driver Type: External Waterproof LED Driver
PF: ＞0.90
Color Temperature: 6500-7000K(Pure White), 7000-7500K(Cold White), 7500-8000K(Cold White)
Luminous Flux: 160-180LM (per Piece)
Main Material: ABS + PMMA
IP Class: IP67
Working Temperature: -40℃~85℃
Working Lifespan: 50,000 Hrs
● Detail Form:
| Input Voltage | CCT | Beam Angle | CRI | IP Class |
| DC12V | 6500-8000K |
15*45° |
＞80 |
IP67 |
| Item No. | Product Dimensions | Power Consumption | Light Source | Luminous Flux / Piece |
| AL-LM1.5D-1LED3030-1P-12V | L48*W31*T15 (mm) | 1.5W | 1PC SMD3030 | 160-180LM |
● Advantages:
Use Imported Cree LEDs, Excellent Quality, Super Long Working LifespanEach Module has Φ5mm Screw Hole and Imported 3M Tape attached, Easy Installation and Maintenance
DC12V Low Voltage Input, Safe and No Hidden Dangers
PMMA Lens, Excellent Light Transmittance Effect, Uniform Light Color and No Glare
The Module Quantity of Each String can Reach 20PCS, IP67 Waterproof, Best Choice for the Backlight of Huge Outdoor Advertising Light Box
PSE Approved, Gorgeous Product for Japan Market
No Flicker, No Radiation, Environmental Friendly and Energy Saving
● Applications:
Advertising Light Box, Advertising Signboard, Cabinet, Corridor, Supermarket, Cloth Store, Museum, Hospital, KTV, Architecture, Theatre, Cinema, Hotel, Cafe, Park, Commercial Centre, Villa, etc.
● Certificates:
CE, RoHS, PSE
● Warranty:
3 Years
