UV LED Curing Light
- Item No：LVPCB20-738-UV18LED1W-1P-12V
- views：215
Parameter Feature Detail Application
Item Name: DC12V 21.6W UV (Ultra-violet) Constant Current High Power LED Strip
Item No.: LVPCB20-738-UV18LED1W-1P-12V
Brand Name: AUXOLED
● Specific Parameters:
Product Dimensions: W20*L738*H7 (mm)
Light Source: 18PCS High Power 1W UV LEDs
Chip Brand: Epiled
Beam Angle: 140°
Input Voltage: DC12V
Power Consumption: 21.6W
LED Wave Length: 380-385NM, 385-390NM, 390-395NM, 395-400NM, 400-405NM, 405-410NM
Luminous Flux: 216LM (UV)
PCB Material: 2MM Thick Aluminum Base
Working Temperature: -30℃~65℃
Working Lifespan: 50,000 Hrs
2MM Thick Aluminum PCB Base, Gorgeous Heat Sink Effect
Using High Quality Silicone Molding Lens for LEDs, 140° Super Wide Beam Angle, Uniform Light Ray, Anti-glare
UL Complied Red & Black Soldering Wires, Safe and Environmental-friendly, Fine Processed
7 Mounting Holes for Each Strip Designed, Not Only Can fit Different Application Occasions, But Also Offer Convenience to Installation and Maintenance
DC12V Low Input Voltage, Constant Current Design, Stable, Safe and No Hidden Dangers
No Flicker, No Radiation, Environmental Friendly and Energy Saving
● Applications:
Bacteria Killing, Gauze Mask (Mouth Muffle) Disinfection, Skin Care, Detecting Currency, Printing (Curing Ink), Improving Plant Growing Condition, Fishing, Mosquito Eradication, Moth & Insect Luring, Manicure, Food Sterilization & Fresh Keeping Packaging, Medical Treatment & Public Health, Detecting Bloodstain, Communication Technology, Decoration and Illumination, Aerospace, Air & Water Purification Treatment, etc.
● Certificates:
CE, RoHS
● Warranty:
Item No.: LVPCB20-738-UV18LED1W-1P-12V
Brand Name: AUXOLED
● Specific Parameters:
Product Dimensions: W20*L738*H7 (mm)
Light Source: 18PCS High Power 1W UV LEDs
Chip Brand: Epiled
Beam Angle: 140°
Input Voltage: DC12V
Power Consumption: 21.6W
LED Wave Length: 380-385NM, 385-390NM, 390-395NM, 395-400NM, 400-405NM, 405-410NM
Luminous Flux: 216LM (UV)
PCB Material: 2MM Thick Aluminum Base
Working Temperature: -30℃~65℃
Working Lifespan: 50,000 Hrs
● Detail Form:
| Input Voltage | Wave Length | Beam Angle | PCB Thickness | IP Class |
| DC12V / DC36V | 380-410nm |
140° |
2 (mm) | IP20 |
| Item No. | Product Dimensions | Rated Power | Light Source | Luminous Flux (UV) |
| LVPCB15-550-15LED1W-1P-12V | W15*L550*T7 (mm) | 18W | 15PCS*1W | 180LM |
|
LVPCB20-738-18LED1W-1P-12V |
W20*L738*T7 (mm) |
21.6W | 18PCS*1W | 216LM |
|
LVPCB18-1000-18LED1W-1P-12V |
W18*L1000*T7 (mm) |
21.6W | 18PCS*1W | 216LM |
|
LVPCB20-750-10LED2W-1P-36V |
W20*L750*T7 (mm) |
19.8W | 10PCS*2W | 150LM |
|
LVPCB20-1190-16LED2W-1P-12V |
W20*L1190*T7 (mm) |
32W | 16PCS*2W | 240LM |
● Advantages:
Use Imported Epiled LED Chips, Super Long Working Lifespan2MM Thick Aluminum PCB Base, Gorgeous Heat Sink Effect
Using High Quality Silicone Molding Lens for LEDs, 140° Super Wide Beam Angle, Uniform Light Ray, Anti-glare
UL Complied Red & Black Soldering Wires, Safe and Environmental-friendly, Fine Processed
7 Mounting Holes for Each Strip Designed, Not Only Can fit Different Application Occasions, But Also Offer Convenience to Installation and Maintenance
DC12V Low Input Voltage, Constant Current Design, Stable, Safe and No Hidden Dangers
No Flicker, No Radiation, Environmental Friendly and Energy Saving
● Applications:
Bacteria Killing, Gauze Mask (Mouth Muffle) Disinfection, Skin Care, Detecting Currency, Printing (Curing Ink), Improving Plant Growing Condition, Fishing, Mosquito Eradication, Moth & Insect Luring, Manicure, Food Sterilization & Fresh Keeping Packaging, Medical Treatment & Public Health, Detecting Bloodstain, Communication Technology, Decoration and Illumination, Aerospace, Air & Water Purification Treatment, etc.
● Certificates:
CE, RoHS
● Warranty:
2 Years
