UVC LED Sterilizer Bar
- Item No：LVPCB14-160-UVC4W-2P-5V
- views：169
Parameter Feature Detail Application
Item Name: DC5V 4W UVC (Ultra-violet) Masks/Bags/Suitcases/Kitchen Disinfection Sterilizing LED Light Strip
Item No.: LVPCB14-160-UVC4W-2P-5V
Brand Name: AUXOLED
● Specific Parameters:
Product Dimensions: W14*L160*T2 (mm)
Light Source: 4W UVC + UVA LEDs (Dual Strips)
Chip Brand: Epiled
Beam Angle: 120°
Input Voltage: DC5V (USB Available)
Power Consumption: 4W (Dual Strips)
LED Wave Length: 275-280nm+395nm
PCB Material: 2MM Thick Aluminum Base
Working Temperature: -30℃~65℃
Working Lifespan: 50,000 Hrs
2MM Thick High Heat Conductivity Coefficient Aluminum PCB Base, Gorgeous Heat Sink Effect
Mechanical Switch + Delay ON & Auto-OFF Solution: 1st Solution - 10 Seconds Power-ON Delay, Fixed Delay Auto-OFF Time, 1min to 15 Hrs Optional, Once Chosen, We Would Define the Delay Time as per Required before Leaving Our Factory, Non-adjustable to Users; 2nd Solution - 10 Seconds Power-ON Delay (This Function is Optional), 5mins / 15mins / 30mins Delay Auto-OFF Switchable Wireless Remote Switch + Delay ON & Delay Auto-OFF Solution: 10 Seconds Power-ON Delay (Fixed), 1min to 15 hrs Delay Auto-OFF Adjustable to Users; Regular Remote Emitter - One Key (ON / OFF), Two Keys (ON & OFF) Optional, Remote Distance 20-30M without Barriers, Can Get Through Walls, Efficient Distance is approximate 10-20M; Moreover, 1KM Super Long Remote Controller is Available
Electromagnetic Switch Solution: Electromagnetic Switch now is At Service, An Elegant and Smart Way to Control the ON / OFF
Can Add Clear Quartz Glass Lamp Cover, Light Transmittance is High, Anti-UV with long life, Large Lighting Beam Angle; Portable Design, Small Figure, Light Weight, Can Carry This Safeguard Freely
DC5V (USB Available) Low Input Voltage, Can Work with Power Bank, Safe and No Hidden Dangers
No Flicker, Environmental Friendly and Energy Saving
275-280nm + 395nm UV LEDs, Born for Easy, Fast & Efficient Lighting and Disinfection, Sterilization of Kitchen, Underwear, Masks, Bags, Suitcase, etc., Can Eliminate 99.9% Bacterias
Can Connect More Pieces for Different Application Needs
Portable Design, Small Figure, Light Weight, Can Carry This Safeguard Freely
No Flicker, Environmental Friendly and Energy Saving
● Applications:
Bacteria Killing, Gauze Mask (Mouth Muffle) Disinfection, Skin Care, Detecting Currency, Printing (Curing Ink), Improving Plant Growing Condition, Fishing, Mosquito Eradication, Moth & Insect Luring, Manicure, Food Sterilization & Fresh Keeping Packaging, Medical Treatment & Public Health, Detecting Bloodstain, Communication Technology, Decoration and Illumination, Aerospace, Air & Water Purification Treatment, etc.
● Certificates:
CE, RoHS
● Warranty:
Item No.: LVPCB14-160-UVC4W-2P-5V
Brand Name: AUXOLED
● Specific Parameters:
Product Dimensions: W14*L160*T2 (mm)
Light Source: 4W UVC + UVA LEDs (Dual Strips)
Chip Brand: Epiled
Beam Angle: 120°
Input Voltage: DC5V (USB Available)
Power Consumption: 4W (Dual Strips)
LED Wave Length: 275-280nm+395nm
PCB Material: 2MM Thick Aluminum Base
Working Temperature: -30℃~65℃
Working Lifespan: 50,000 Hrs
● Detail Form:
| Input Voltage | Wave Length | Beam Angle | PCB Thickness | IP Class |
| DC5V (USB) | 275-280nm + 395nm |
120° |
2 (mm) | IP20 |
| Item No. | Product Dimensions | Rated Power | Light Source | PCB Material |
| LVPCB14-160-UVC4W-2P-5V | W14*L160*T2 (mm) | 4W (Dual Strips) | 4W UVC+UVA LEDs | Aluminum |
● Advantages:
Use Imported Epiled LED Chips, Super Long Working Lifespan2MM Thick High Heat Conductivity Coefficient Aluminum PCB Base, Gorgeous Heat Sink Effect
Mechanical Switch + Delay ON & Auto-OFF Solution: 1st Solution - 10 Seconds Power-ON Delay, Fixed Delay Auto-OFF Time, 1min to 15 Hrs Optional, Once Chosen, We Would Define the Delay Time as per Required before Leaving Our Factory, Non-adjustable to Users; 2nd Solution - 10 Seconds Power-ON Delay (This Function is Optional), 5mins / 15mins / 30mins Delay Auto-OFF Switchable Wireless Remote Switch + Delay ON & Delay Auto-OFF Solution: 10 Seconds Power-ON Delay (Fixed), 1min to 15 hrs Delay Auto-OFF Adjustable to Users; Regular Remote Emitter - One Key (ON / OFF), Two Keys (ON & OFF) Optional, Remote Distance 20-30M without Barriers, Can Get Through Walls, Efficient Distance is approximate 10-20M; Moreover, 1KM Super Long Remote Controller is Available
Electromagnetic Switch Solution: Electromagnetic Switch now is At Service, An Elegant and Smart Way to Control the ON / OFF
Can Add Clear Quartz Glass Lamp Cover, Light Transmittance is High, Anti-UV with long life, Large Lighting Beam Angle; Portable Design, Small Figure, Light Weight, Can Carry This Safeguard Freely
DC5V (USB Available) Low Input Voltage, Can Work with Power Bank, Safe and No Hidden Dangers
No Flicker, Environmental Friendly and Energy Saving
275-280nm + 395nm UV LEDs, Born for Easy, Fast & Efficient Lighting and Disinfection, Sterilization of Kitchen, Underwear, Masks, Bags, Suitcase, etc., Can Eliminate 99.9% Bacterias
Can Connect More Pieces for Different Application Needs
Portable Design, Small Figure, Light Weight, Can Carry This Safeguard Freely
No Flicker, Environmental Friendly and Energy Saving
● Applications:
Bacteria Killing, Gauze Mask (Mouth Muffle) Disinfection, Skin Care, Detecting Currency, Printing (Curing Ink), Improving Plant Growing Condition, Fishing, Mosquito Eradication, Moth & Insect Luring, Manicure, Food Sterilization & Fresh Keeping Packaging, Medical Treatment & Public Health, Detecting Bloodstain, Communication Technology, Decoration and Illumination, Aerospace, Air & Water Purification Treatment, etc.
● Certificates:
CE, RoHS
● Warranty:
2 Years
