RGB Luxury Stone LED Panel Light
- Item No：FPC245-490-128LED5050TC-3P-24V
- views：9
Parameter Feature Detail Application
Item Name: DC24V 45W RGB2835 FPC Luxury Stone Flexible LED Panel Light / Board Light / Strip Backlight
Item No.: FPC245-490-128LED5050TC-3P-24V
Brand Name: AUXOLED
● Specific Parameters:
Product Dimensions: W245*L490*T2.1 (mm)
Light Source: 128PCS RGB5050 LEDs
Chip Brand: Epistar or Epiled
Beam Angle: 120°
CRI: ＞90
Input Voltage: DC12V / DC24V
Power Consumption: 45W
Emitting Color: RGB
Luminous Flux: 100LM/W (White Color)
PCB Material: FPC
IP Class: IP20 / IP54
Working Temperature: -20℃~45℃
Working Lifespan: 50,000 Hrs
Can be Soldered into Bigger Size, Suitable for Using as the Backlight of LED Light Box and LED Panel Light
FPC RA Copper Base, Flexible and Good Ductility, Not Easy to Damage
Multi Emitting Color Optional: White, Red, Green, Blue, RGB, RGBW, RGBWCW, Can Meet Different Desires of Lighting and Illumination
DC12V or DC24V Low Input Voltage, Safe and No Hidden Dangers
No Flicker, No Radiation, Environmental Friendly and Energy Saving
● Applications:
Supermarket, Shopping Centre, KTV, Architecture, Theatre, Cinema, Exhibition Hall, Cabinet, Kitchen, Counter, Corridor, Cafe, Hotel, Park, Advertising Backlight, Accent Lighting, Sign Illumination, Cove Lighting, etc.
● Certificates:
CE, RoHS
● Warranty:
Item No.: FPC245-490-128LED5050TC-3P-24V
Brand Name: AUXOLED
● Specific Parameters:
Product Dimensions: W245*L490*T2.1 (mm)
Light Source: 128PCS RGB5050 LEDs
Chip Brand: Epistar or Epiled
Beam Angle: 120°
CRI: ＞90
Input Voltage: DC12V / DC24V
Power Consumption: 45W
Emitting Color: RGB
Luminous Flux: 100LM/W (White Color)
PCB Material: FPC
IP Class: IP20 / IP54
Working Temperature: -20℃~45℃
Working Lifespan: 50,000 Hrs
● Detail Form:
| Input Voltage | Emitting Color | Beam Angle | CRI | IP Class |
| DC12V / DC5V | W/R/G/B/RGBW/RGBWCW |
120° |
＞90 |
IP20 / IP54 |
| Item No. | Product Dimensions | Rated Power | Light Source | Luminous Flux |
| FPC245-490-242LED2835-1P-24V | W245*L490*T2.1 (mm) | 36W | 242PCS SMD2835 | 100LM/W |
|
FPC245-490-384LED2835TC-1P-24V |
W245*L490*T2.1 (mm) |
45W | 384PCS SMD2835 | 100LM/W |
|
FPC245-490-98LED2835-1P-24V |
W245*L490*T2.1 (mm) |
20W | 98PCS SMD2835 | 100LM/W |
|
FPC245-490-484LED2835DC-1P-24V |
W245*L490*T2.1 (mm) |
48W | 484PCS SMD2835 | 100LM/W |
|
FPC245-490-120LED5050TC-1P-24V |
W245*L490*T2.1 (mm) |
45W | 120PCS SMD5050 | 100LM/W (White Only) |
|
FPC245-490-288LED5050RGBW-1P-24V |
W245*L490*T2.1 (mm) |
48W | 288PCS SMD5050 | 100LM/W (White Only) |
|
FPC245-490-105LED5050RGBW-1P-24V |
W245*L490*T2.1 (mm) |
28W | 105PCS SMD5050 | 100LM/W (White Only) |
|
FPC245-490-360LED5050RGBWCW-1P-24V |
W245*L490*T2.1 (mm) |
75W | 360PCS SMD5050 | 100LM/W (White Only) |
● Advantages:
Use Imported Epistar Chip LEDs, Super Long Working LifespanCan be Soldered into Bigger Size, Suitable for Using as the Backlight of LED Light Box and LED Panel Light
FPC RA Copper Base, Flexible and Good Ductility, Not Easy to Damage
Multi Emitting Color Optional: White, Red, Green, Blue, RGB, RGBW, RGBWCW, Can Meet Different Desires of Lighting and Illumination
DC12V or DC24V Low Input Voltage, Safe and No Hidden Dangers
No Flicker, No Radiation, Environmental Friendly and Energy Saving
● Applications:
Supermarket, Shopping Centre, KTV, Architecture, Theatre, Cinema, Exhibition Hall, Cabinet, Kitchen, Counter, Corridor, Cafe, Hotel, Park, Advertising Backlight, Accent Lighting, Sign Illumination, Cove Lighting, etc.
● Certificates:
CE, RoHS
● Warranty:
2 Years
